CE-109-S-626 TownSteel Cylindrical Lock

The CE Series Cylindrical Lock is designed for High Traffic commercial areas such as schools, universitis, office buildings, and industrial complexes. The CE is certified ANSI/BHMA A156.2-2011 4000 Series Grade 1 and UL10C 3 Hour Rated. Featuring an internal spring design that mitigates lever sag, and allows for an aesthetically pleasing low projection rose. The CE series is available with a standard Schlage C keyway as well as SFIC, Schlage LFIC, Corbin LFIC, and TownSteel High Security Cylinders.

CE Series

• Door Thickness: 1-3/4" - 2"
• Backset: 2-3/4" Standard, 5" Optional
• Latch Bolt: Stainless Steel, 1/2" throw
• Faceplate: Self-adjustable, 1-1/8" x 2-1/4" Stainless Steel

CDC Series

• Door Thickness: 1-3/8" - 2"
• Backset: 2-3/4" Standard, 2-3/8", 3-3/4", 5" Optional
• Latch Bolt: Stainless Steel, 1/2" (12.7mm) throw, deadlocking on keyed functions. Anti-friction fire door latch with 3/4" (19mm) throw available upon request
• Faceplate: Forged brass or Stainless Steel, 1-1/8" X 2-1/4" (29mm X 57mm) square corner, beveled.
