10LO21 BEA Relay

The LO21 Provides Optional Safety Beam Input to Override the Inhibit Signal During Closing. When the Safety Beam Path is Blocked or Interrupted During Closing, the Inhibit Data Will be Cancelled, Thus Initiating a Safety Signal to the Door Control Safety Input.

Notable Features Include:

• Logic module with integrated 900 MHz wireless technology eliminates the need for separate logic module and wireless receiver (Br2-900)
• Sequenced or simultaneous relay activation for application flexibility (Br2-900)
• 2-AMP relays allow the direct release of an electric locking device wirelessly, eliminating the need for a separate logic module or isolation relay (Br2-900)
• Extended Hold Mode allows wireless push plates to function like hardwired push plates (if push plate is held, relay does not time out) (Br2-900)
• Wireless functionality eliminates the need to run input wires directly to the logic module, saving both time and money (Br2-900)
• Dry auxiliary input for overriding Day / Night Mode (Br2-900)

• Versatility with 13 programmable logic functions for the BR3-X
• Two-button programming combined with dual seven-segment display provides simple setup (BR3-X)
• Two 3-AMP relays and one 1-AMP relay, all with built-in surge suppression, eliminates the need for external components when installing some electric locking devices (BR3-X)
• WET output with AC / DC voltage for powering an electric locking device directly from the module (BR3-X)
