Description
The Sargent 80 Series rim exit device delivers Grade 1 security and durability for wood or metal doors in high-traffic commercial facilities. This single-point latching device is ideal for building managers and facility owners who need reliable panic hardware that meets ANSI/BHMA standards, offers quiet operation, and requires minimal maintenance thanks to modular construction and few moving parts.
The 125556-8840F model suits F Rail door widths from 33 to 36 inches with no cutting required for 36-inch doors. Installation fits standard 1 3/4-inch thick doors; thicker doors available upon request. As an authorized Sargent dealer, E.D. Locks provides expert configuration guidance and compatibility verification. Contact sales@edlocks.com or call 1-877-207-6067 for assistance selecting the right rail size and optional features like alarmed exit or electric latch retraction.
Specifications
- Brand: Sargent
- Model: 125556-8840F BSP
- Type: Rim Exit Device
- Configuration: F Rail
- Door Width Range: 33 to 36 inches (84 to 91 cm)
- Door Thickness: 1 3/4 inches (44 mm)
- Door Types: Wood or metal
- Latching: Single point
- Applications: Single door and double door with mullions
- Certification: ANSI A156.3 Grade 1, UL Fire and Panic listed
- Features: Quiet operation, modular construction, minimal maintenance
