Description
The LCN 1460-3048L AL is a Grade 1 commercial door closer designed for maximum versatility in both commercial and institutional settings. Built with a cast iron body, full complement bearing, and adjustable spring sizes (1-6), this closer solves the challenge of finding a reliable, durable solution for doors up to 5'0" interior or 4'0" exterior. It mounts on the hinge side, top jamb, or as a parallel arm on either right or left swinging doors.
This non-handed cylinder is fully reversible and compatible with multiple cover options including Standard Slim Line, Full, and Designer Series finishes. All adjustment valves remain concealed to prevent tampering. For expert guidance on compatibility, installation, and finish options like optional SRI primer for corrosive environments, contact our authorized dealer specialists at sales@edlocks.com or 1-877-207-6067. We deliver personalized support to ensure proper selection and setup.
Specifications
- Grade 1 door closer
- Cast iron body with full complement bearing
- Piston diameter: 1-1/4 inches
- Pinion journal: 3/4 inch diameter, heat treated
- Spring sizes: adjustable 1 to 6
- Interior door capacity: up to 5'0"
- Exterior door capacity: up to 4'0"
- Mounting options: hinge side, top jamb, parallel arm
- Mounting: right or left swinging doors
- All weather fluid included
- ADA compliant
- Tested to 2,000,000 cycles
- Finish options: standard powder coat, optional plated, optional SRI primer
