Description
The LCN 1460-61 is a Grade 1 commercial door closer designed for versatility in both institutional and commercial settings. Built with a cast iron body, full complement bearing, and adjustable spring strength (sizes 1-6), it solves the need for reliable, durable door control on interior and exterior applications up to 5'0" and 4'0" respectively. The US26D finish delivers corrosion resistance.
This closer mounts on the hinge side, top jamb, or parallel arm for right or left swinging doors, and meets ADA requirements. It features concealed adjustment valves for backcheck, closing and latching speeds, plus a Cush-N-Stop function to prevent damage. As an authorized LCN dealer, E.D. Locks provides expert installation guidance and support. Contact sales@edlocks.com or call 1-877-207-6067 for compatibility questions or technical assistance.
Specifications
- Brand: LCN
- Model: 1460-61
- Grade: 1
- Finish: US26D
- Body Material: Cast iron
- Piston Diameter: 1-1/4 inch
- Pinion Journal: 3/4 inch diameter, heat treated
- Spring Adjustment: Sizes 1-6
- Interior Door Range: Up to 5'0"
- Exterior Door Range: Up to 4'0"
- Cycle Tested: 2,000,000 cycles
- Mount Options: Hinge side, top jamb, parallel arm
- Handed: Universal, fully reversible
- ADA Compliant: Yes
- Includes: Regular arm, slim line plastic cover, self-reaming and tapping screws
