Description
The Sargent 19-8504F is a heavy-duty rim exit device built for commercial doors requiring Grade 1 security and durability. Designed for wood or metal doors 1 3/4 inches thick, this right-hand reverse model combines modular construction with minimal moving parts to deliver maintenance-free operation and long-term reliability in demanding facilities.
Compatible with door widths 24 to 48 inches using E, F, J, or G rails (no cutting required for standard sizes). The 80 Series exceeds ANSI/BHMA Grade 1 standards and supports optional delayed egress, alarm, and electric latch retraction functions. Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for expert assistance selecting the right configuration and rail size for your application.
Specifications
- Brand: Sargent
- Model: 19-8504F
- Series: 80 Series
- Configuration: Rim, Right-Hand Reverse (RHR)
- Door Types: Wood or metal
- Door Thickness: 1 3/4 inch (44mm) standard; over 1 3/4 inch specify thickness and order with 31- prefix
- Minimum Stile Width: 1 3/4 inch (44mm)
- Compatible Door Widths: 24-32 inch (E Rail), 33-36 inch (F Rail), 37-42 inch (J Rail), 43-48 inch (G Rail)
- Standards: Exceeds ANSI/BHMA Grade 1
- Optional Features: Delayed egress, alarmed exit, electric latch retraction
