Description
The Sargent 80 Series rim exit device is a heavy-duty panic hardware solution for wood and metal doors in commercial and institutional facilities. Designed for environments demanding exceptional durability and security, it exceeds ANSI/BHMA Grade 1 requirements and features modular construction with minimal moving parts for maintenance-free operation throughout the building's life.
This LHR (left-hand reverse) model suits 1-3/4 inch doors and fits E, F, J, or G rail configurations depending on door width (24 to 48 inches available). Options include delayed egress, alarmed exit, and electric latch retraction for specialized applications. Contact an E.D. Locks authorized dealer at sales@edlocks.com or 1-877-207-6067 for expert guidance on selection, compatibility, and installation support.
Specifications
- Brand: Sargent
- Series: 80 Series
- Model: 19-8543F
- Configuration: Rim, LHR (Left-Hand Reverse)
- Door Thickness: 1-3/4 inch (44mm)
- Door Width Range: 24 to 48 inches (61cm to 122cm) depending on rail type
- Rail Options: E Rail (24-32 inches), F Rail (33-36 inches), J Rail (37-42 inches), G Rail (43-48 inches)
- Door Types: Wood or metal
- Minimum Stile: 1-3/4 inch (44mm)
- ANSI/BHMA Grade: Exceeds Grade 1
- Available Options: Delayed egress, alarmed exit, electric latch retraction
