Description
The Sargent 80 Series exit device is a Grade 1 certified panic hardware designed for metal doors requiring durable, low-maintenance security. This rim-mounted device suits commercial buildings, healthcare facilities, and high-traffic environments where code compliance and long-term reliability are essential.
Compatible with 1-3/4" to 2-1/4" thick metal doors with 4-1/2" minimum stile width. Modular construction requires minimal maintenance. Available electric options include alarm, latch monitoring, delayed egress, and remote latch retraction. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for sizing guidance, rail selection, and custom configurations.
Specifications
- Grade: ANSI/BHMA Grade 1
- Configuration: Rim, Right-Hand Reverse (RHR)
- Finish: 32D (Satin Stainless Steel)
- Door Types: Metal doors, 1-3/4" to 2-1/4" thick
- Minimum Stile Width: 4-1/2"
- Center Case Dimensions: 8-3/8" x 2-5/8"
- Device Centerline from Floor: 41" (standard), 38" (schools/accessibility)
- Pushbar Projection: 3" (neutral), 2-1/8" (depressed)
- Strike: 650 Top Strike & 606 Bottom Strike
- Top Bolt: Stainless steel
- Dogging: Hex key standard (non-fire rated)
- Available Electric Options: Alarm, Beacon, Photoluminescent, Illuminated Touchpad, Latch Monitoring, Request-to-Exit, Remote Latch Retraction, Delayed Egress, Electric Dogging
- Maximum Door Height: 96"
