Description
The Sargent 80 Series exit device is a heavy-duty panic hardware solution for facilities requiring Grade 1 security and reliability across the building's life. This rim-mounted device with left-hand reverse configuration exceeds ANSI/BHMA standards for cycle and strength, making it ideal for metal doors in commercial, institutional and industrial environments where code compliance and durability matter most.
Designed for 1-3/4" minimum thickness metal doors with modular construction and minimal moving parts, this device installs with supplied machine screws and ships with 650 top and 606 bottom strikes. Compatible with E, F, J and G rail sizes depending on door width. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for specification assistance, keying options, and electric accessory selection.
Specifications
- Configuration: Rim, Left-Hand Reverse (LHR)
- Finish: 32D (Satin Stainless Steel)
- Door Thickness: 1-3/4" (44mm) minimum; up to 2-1/4" with thickness specification
- Minimum Stile Width: 4-1/2" (114mm)
- Device Centerline: 41" (1041mm) standard, 38" (965mm) for ADA/elementary schools
- Center Case Dimensions: 8-3/8" (213mm) x 2-5/8" (67mm)
- Pushbar Projection: 3" (76mm) neutral, 2-1/8" (54mm) depressed
- Top Bolt: Stainless steel
- Maximum Door Height: 96" (HC and WS options), 120" standard
- Rail Options: E (24-32"), F (33-36"), J (37-42"), G (43-48") door widths
- Strikes: 650 Top Strike and 606 Bottom Strike (panic and fire-rated)
- Dogging: Hex key standard on non-fire-rated; cylinder dogging available (#41 cylinder)
- Electric Options: Alarm, Beacon, SARGuide photoluminescent or illuminated touchpad, latch monitoring, request-to-exit signal, remote latch retraction, delayed egress, electric dogging, Electroguard self-contained delayed egress
