Description
The Sargent 80 Series exit device is a heavy-duty panic bar designed for metal doors in commercial and institutional buildings that demand Grade 1 security and reliability. This rim-mounted device with right-hand reverse (RHR) configuration and 32-inch door width rating exceeds ANSI/BHMA Grade 1 cycle and strength requirements, offering maintenance-free operation with modular construction and minimal moving parts.
This device fits metal doors 1.75 inches minimum thickness and accepts standard 650 top and 606 bottom strikes for panic and fire-rated applications. Multiple electric options including delayed egress, alarm, and latch retraction are available. As an authorized Sargent dealer, E.D. Locks provides expert configuration guidance and support. Contact our sales team at sales@edlocks.com or 1-877-207-6067 to specify the right options for your application.
Specifications
- Brand: Sargent
- Model: 1943-WD8615E
- Configuration: RHR (Right-Hand Reverse), Rim Mounted
- Rail Size: E Rail (24 inch to 32 inch door widths)
- Door Thickness: 1.75 inches minimum; 2.25 inches maximum with specification
- Minimum Stile Width: 4.5 inches
- Device Centerline: 41 inches from finished floor (standard); 38 inches for ADA/elementary schools
- Center Case Dimensions: 8.375 inches x 2.625 inches
- Pushbar Projection: 3 inches neutral, 2.125 inches depressed
- Top Bolt: Stainless steel
- Standard Dogging: Hex key (non-fire-rated devices)
- Maximum Door Height: 96 inches
- Grade: ANSI/BHMA Grade 1
