Description
The Sargent 80 Series Rim Exit Device is a heavy-duty egress solution for facilities requiring Grade 1 security and reliability. Designed for wood or metal doors 1-3/4 inches thick, this device exceeds ANSI/BHMA standards with modular construction, few moving parts, and maintenance-free operation. Ideal for commercial buildings, hospitals, and high-traffic environments.
The 194356-8506J fits door widths 24-32 inches with the E Rail (no cutting required for 32-inch doors). Minimum 1-3/4-inch stile width required. Optional configurations include delayed egress, alarmed exit, and electric latch retraction. As an authorized Sargent dealer, E.D. Locks provides expert guidance on installation and keying. Contact our team at sales@edlocks.com or 1-877-207-6067 for compatibility questions or to discuss your specific application.
Specifications
- Brand: Sargent
- Model: 80 Series 194356-8506J
- Type: Rim Exit Device
- Finish: 32D
- Door Thickness: 1-3/4 inches (44mm) wood or metal
- Minimum Stile Width: 1-3/4 inches (44mm)
- Door Width Range (E Rail): 24-32 inches (61-81cm)
- Standard Width: 32 inches (no cutting required)
- Standards: Exceeds ANSI/BHMA Grade 1
- Configuration Options: Rim, mortise, surface vertical, concealed vertical rod
- Additional Options: Delayed egress, alarmed exit, electric latch retraction
