Description
The Sargent 80 Series exit device is a heavy-duty panic hardware solution designed for commercial and institutional facilities requiring Grade 1 security and reliability. This rim-mounted device exceeds ANSI/BHMA Grade 1 cycle and strength requirements, making it ideal for metal doors in high-traffic environments where durability and compliance are non-negotiable.
Compatible with 1-3/4" minimum thickness metal doors, this LHR (left-hand reverse) model includes a 32D finish and factory-cut rail sizing based on door width (E, F, J, or G rail options available). As an authorized Sargent dealer, E.D. Locks provides expert sizing assistance, compatibility verification, and full technical support. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for door specifications and optional features like delayed egress or electric latch retraction.
Specifications
- Brand: Sargent
- Series: 80
- Model: 1956-MD8610E ETJ
- Configuration: Rim, LHR (Left-Hand Reverse)
- Finish: 32D
- Door Type: Metal, 1-3/4" (44mm) minimum thickness
- Door Width Range: 24" to 48" (E, F, J, G rail options)
- Device Centerline Height: 41" (1041mm) standard; 38" (965mm) for accessibility
- Maximum Door Height: 96"
- Center Case Dimensions: 8-3/8" x 2-5/8"
- Pushbar Projection: 3" neutral, 2-1/8" depressed
- Top Bolt: Stainless steel
- Standard Dogging: Hex key (non-fire-rated)
- Strikes: 650 Top, 606 Bottom (panic and fire-rated compatible)
- Certifications: Exceeds ANSI/BHMA Grade 1
