Description
The Von Duprin 3327ANL is a UL-listed panic exit device designed for single and double doors in commercial and institutional buildings. Grade 1 ANSI A156.3-2008 certified, this grooved-case surface vertical rod device provides reliable emergency egress with deadlocking anti-friction bolts. Ideal for schools, hospitals, offices and public venues requiring code-compliant life safety hardware.
The 3327ANL fits door widths from 2'8" to 4', with center case mounting 39 13/16" from finished floor. Compatible with wood and metal doors using included sex bolts. As an authorized Von Duprin dealer, E.D. Locks provides expert specification assistance, competitive pricing, and fast shipping. Contact our team at sales@edlocks.com or 1-877-207-6067 for application questions or to order.
Specifications
- Brand: Von Duprin
- Model: 3327ANL 4 US3 LHR
- Finish: US3 Satin Brass
- Door sizes: 2'8" to 4'
- Center case height: 39 13/16" from finished floor
- Center case dimensions: 8 13/16" x 2 13/32" x 1 9/16"
- Mechanism case dimensions: 2 1/4" x 2 1/4"
- Pushbar projection neutral: 3 13/16"
- Pushbar projection depressed: 3 1/16"
- Latch bolt throw: 5/8"
- Door undercut: 1/4"
- Top and bottom latch dimensions: 4 1/2" x 2 1/8" x 1 1/2"
- Vertical rods: 1/2" square tubing, standard 7' accommodation
- Top rod length: 34 15/16"
- Bottom rod length: 31 1/4"
- Certification: ANSI A156.3-2008 Grade 1, UL Listed
- Compatible with wood and metal doors
