Description
The Von Duprin 33A-ALK is a UL-listed panic exit device for single and double doors. This Grade 1 ANSI A156.3-2014 compliant hardware suits retrofit and new construction projects where code-compliant emergency egress and alarm monitoring are essential.
The ALK alarm exit kit option integrates seamlessly with fire and security systems. Compatible with wood and metal doors 4 feet to 4 feet 10 inches wide; installation requires standard hex key dogging hardware. As an authorized Von Duprin dealer, E.D. Locks provides expert guidance on keying, configuration, and compliance. Contact our team at sales@edlocks.com or 1-877-207-6067 for application support.
Specifications
- Model: 33A-ALK 4FT 315
- Grade: ANSI A156.3-2014 Grade 1
- Door Width Range: 4'2" to 4'10" (864mm to 1219mm)
- Finish: Dull Black strike
- Latch Bolt: Deadlocking, 3/4" (19mm) throw
- Case Dimensions: 8 3/16" x 2 13/32" x 1 9/16" (208mm x 62mm x 40mm)
- Centerline Height: 39 13/16" from finished floor
- Pushbar Neutral Projection: 3 13/16" (97mm)
- Dogging: Hex key standard; CD Cylinder or LD Less Dogging options available
- Fasteners: Sex Bolts #425 (1 3/4" to 2 1/4") for wood and metal doors
- Function: Alarm exit kit with latchbolt monitoring capability
