Von Duprin 33ANL 3 US3 RHR Exit Device, 3-Wide, US3 RHR

Grade 1 Rim Exit Device, Narrow Stile Pushpad, 36", Night Latch, Escutcheon Pull, Hex Key Dogging, Bright Brass Finish, Right-Hand Reverse

MSRP: $4,091.00
$2,777.65
You save $1,313.35
SKU:
33ANL 3 US3 RHR
In Stock & Ready To Ship!
Current Stock:Only left:

Description

The Von Duprin 33ANL is a Grade 1 panic exit device designed for single and double doors with mullion. Built to ANSI A156.3-2014 standards and UL-listed, it solves the critical need for reliable emergency egress on commercial doors. Its grooved mechanism case and non-handed rim design (except with signal switch option) make it adaptable across facility layouts.

This 3-wide device fits doors 2'4" to 3' tall and accommodates wood or metal installations with included sex bolts. Configure it with dogging options, electric latch retraction, monitor switches, or alarm kits to match your security needs. As an authorized Von Duprin dealer, E.D. Locks provides expert guidance on compatibility and installation. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for personalized support.

Specifications

  • Brand: Von Duprin
  • Model: 33ANL 3 US3 RHR
  • Grade: ANSI A156.3-2014 Grade 1
  • Device Width: 3 inches
  • Finish: US3 (Dull Black)
  • Handing: RHR (Right Hand Reverse)
  • Door Size Range: 2'4" to 3' (711mm to 914mm)
  • Latch Bolt: Deadlocking, 3/4" throw
  • Centerline Height: 39 13/16" from finished floor
  • Center Case Dimensions: 8 3/16" x 2 13/32" x 1 9/16"
  • Mechanism Case Dimensions: 2 1/4" x 2 1/4"
  • Pushbar Projection (Neutral): 3 13/16"
  • Pushbar Projection (Depressed): 3 1/16"
  • Dogging: Hex key standard; optional CD or LD
  • Optional Features: Electric latch retraction, monitor switches, alarm kit, pneumatic latch retraction, glass bead kit
