Description
The Adams Rite 3701A36B is a fire-rated rim exit device designed for 36-inch aluminum doors in commercial and institutional settings. This alarmed pushbar meets life-safety codes and suits standard 1-3/4-inch door thickness, solving security and emergency egress requirements for high-traffic facilities.
Compatible with standard mortise cylinders (MS cam) and field-reversible lever trim, this exit device installs with self-tapping screws on doors with minimum 5-inch stiles. As an authorized Adams Rite dealer, E.D. Locks provides expert sizing, handing, and keying guidance. Contact sales@edlocks.com or call 1-877-207-6067 for assistance selecting the right cylinder, dogging option, or finish.
Specifications
- Brand: Adams Rite
- Model: 3701A36B
- Pushbar Length: 36 inches
- Door Thickness: 1-3/4 inches standard (modifiable for thicker doors)
- Material: Extruded aluminum pushbar, anodized finishes available
- Minimum Stile Width: 5 inches
- Projection: 2-5/8 inches (fully projected), 1-5/8 inches (dogged)
- Strikes: Stainless steel, included
- Cylinder: Accepts standard mortise cylinder with MS cam (sold separately)
- Dogging: Standard hex key or optional cylinder/electric dogging
- Fasteners: Self-tapping screws (optional Sex Bolt Kits available)
- Fire Rated: Yes
- Alarmed: Yes
- Warranty: Five year limited
