Description
The LCN 4040XP-H is a heavy-duty door closer built for institutional and high-traffic commercial environments. Its cast iron body, forged steel arm, and double heat-treated steel pinion deliver durability in demanding applications. The non-sized cylinder adjusts for interior doors to 5'0" and exterior doors to 4'0", meeting ADA requirements and ANSI A156.4 Grade 1 standards.
The PA 695 arm assembly provides reliable performance in all weather conditions with all-weather fluid. UL and cUL listed for self-closing doors, this closer suits schools, hospitals, offices, and public buildings. As an authorized LCN dealer, E.D. Locks offers expert guidance on sizing, installation, and compliance. Contact sales@edlocks.com or call 1-877-207-6067 for technical support and to verify compatibility with your door setup.
Specifications
- Brand: LCN
- Model: 4040XP-H with PA 695 arm
- Body Material: Cast iron
- Arm Material: Forged steel
- Pinion: Double heat-treated steel
- Interior Door Range: Up to 5'0"
- Exterior Door Range: Up to 4'0"
- Fluid: All-weather
- ADA Compliant: Yes
- UL Listed: Yes
- cUL Listed: Yes
- ANSI Standard: A156.4 Grade 1
