Description
The Sargent 4356 80 Series exit device is a heavy-duty panic bar solution built for commercial facilities demanding ANSI/BHMA Grade 1 certified security and durability. Ideal for metal doors in schools, offices, hospitals and industrial settings, this rim-mounted device combines modular construction with minimal maintenance to protect life-safety egress for decades.
This right-hand reverse unit fits doors 37" to 42" wide (J rail) and installs with supplied machine screws at 41" from finished floor. Multiple electric options including delayed egress, alarm, photoluminescent coating and remote latch retraction are available for specialized applications. Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for free expert configuration guidance and to verify compatibility with your specific door and code requirements.
Specifications
- Model: 4356-AD8606J RHR 32D
- Series: 80 Series
- Configuration: Rim, Right-Hand Reverse
- Door Width Range: 37" to 42" (J Rail)
- Door Thickness: 1-3/4" minimum (up to 2-1/4" with special order)
- Minimum Stile Width: 4-1/2"
- Device Centerline Height: 41" (standard), 38" (elementary/accessible)
- Maximum Door Height: 96"
- Center Case Dimensions: 8-3/8" W x 2-5/8" H
- Pushbar Projection: 3" neutral, 2-1/8" depressed
- Strike: 650 Top, 606 Bottom (panic and fire-rated)
- Fasteners: Machine screws supplied, stainless steel top bolt
- Dogging: Hex key standard (cylinder dogging available with 16- option)
- Certification: Exceeds ANSI/BHMA Grade 1
