Description
The Sargent 4356 80 Series exit device is a Grade 1 panic hardware solution for metal doors requiring durable, code-compliant egress. Ideal for commercial buildings, schools, and facilities prioritizing long-term security and reliability, this rim-mounted device exceeds ANSI/BHMA standards with modular construction and minimal maintenance needs.
This right-hand reverse (RHR) model fits 32-inch door widths and accepts optional electric features including delayed egress, alarms, and latch monitoring. Mounting fasteners and stainless steel hardware are included. Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for compatibility verification, rail sizing, and installation guidance from certified security specialists.
Specifications
- Model: 4356-WD8610F ETW RHR 32D
- Configuration: Rim, Right-Hand Reverse
- Door Thickness: 1-3/4 inch minimum (44mm)
- Door Width: 32 inches (E Rail, no cutting required)
- Device Centerline Height: 41 inches from finished floor (standard)
- Center Case Dimensions: 8-3/8 inch x 2-5/8 inch
- Pushbar Projection: 3 inches neutral, 2-1/8 inches depressed
- Maximum Door Height: 96 inches
- Strike: 650 Top and 606 Bottom (panic and fire rated)
- Dogging: Hex key standard; cylinder dogging available
- Fasteners: Machine screws supplied; stainless steel top bolt
- Standards: ANSI/BHMA Grade 1 compliant
