Description
The Sargent 80 Series exit device is a heavy-duty push bar panic hardware built for metal doors requiring Grade 1 security and compliance. Designed for facilities where durability and code adherence matter, this rim-mounted device handles high-traffic environments while maintaining unsurpassed reliability throughout the building's life.
This left-hand reverse 32-inch J-rail model fits doors 37 to 42 inches wide and 1-3/4 inches minimum thickness. Install with supplied stainless steel fasteners at 41 inches from finished floor. Need delayed egress, monitoring, or electric options? Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for expert configuration guidance and fast shipping.
Specifications
- Brand: Sargent
- Model: 4356-WD8615J ETJ LHR 32D
- Type: Rim Exit Device, Panic Hardware
- Configuration: Left-Hand Reverse, 32-inch J-Rail
- Door Width Range: 37 to 42 inches
- Door Thickness: 1-3/4 inches minimum
- Minimum Stile Width: 4-1/2 inches
- Device Centerline: 41 inches from finished floor (standard)
- Center Case Dimensions: 8-3/8 inches x 2-5/8 inches
- Pushbar Projection (Neutral): 3 inches
- Pushbar Projection (Depressed): 2-1/8 inches
- Top Bolt Material: Stainless steel
- Fasteners: Machine screws, supplied standard
- Grade: ANSI/BHMA Grade 1
- Dogging: Hex key standard (non-fire-rated)
- Compatible Strikes: 650 Top Strike, 606 Bottom Strike
