Description
The Sargent 80 Series 55-8504E 10B is a heavy-duty rim exit device designed for commercial buildings requiring maximum security and durability. Ideal for wood or metal doors, it exceeds ANSI/BHMA Grade 1 standards with modular construction and minimal moving parts, delivering maintenance-free operation and reliable performance throughout the building's lifecycle.
This rim configuration fits doors 24" to 48" wide with multiple rail options (E, F, J, G) that require no cutting for standard widths. Compatible with 1-3/4" thick doors; specify thickness for doors over 1-3/4". Options include delayed egress, alarmed exit, and electric latch retraction for specialized applications. Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for expert assistance selecting the right configuration and ordering guidance.
Specifications
- Brand: Sargent
- Series: 80
- Model: 55-8504E 10B
- Type: Rim Exit Device
- Door Thickness: 1-3/4" (44mm) standard; specify for thicker doors
- Minimum Stile Width: 1-3/4" (44mm)
- E Rail Door Width Range: 24" to 32" (61cm to 81cm)
- F Rail Door Width Range: 33" to 36" (84cm to 91cm)
- J Rail Door Width Range: 37" to 42" (94cm to 107cm)
- G Rail Door Width Range: 43" to 48" (110cm to 122cm)
- Compatible Door Types: Wood or metal
- Standard: Exceeds ANSI/BHMA Grade 1
