Description
The Sargent 80 Series rim exit device is a Grade 1 panic hardware solution designed for commercial facilities requiring durable, long-lasting egress control. Built with modular construction and minimal moving parts, it delivers maintenance-free operation and exceptional security for wood or metal doors up to 1-3/4" thick. Its J rail configuration spans 37" to 42" door widths with no cutting required for 42" doors.
This rim-mounted device is compatible with standard hollow metal and wood door frames and installs directly to the interior face. Optional features include delayed egress, alarmed exit, and electric latch retraction for specialized applications. As an authorized Sargent dealer, E.D. Locks provides expert specification guidance and fast shipping. Contact our team at sales@edlocks.com or 1-877-207-6067 for installation support or custom configurations.
Specifications
- Series: Sargent 80
- Configuration: Rim
- Door Thickness: 1-3/4" (44mm) standard
- Rail Type: J Rail
- Door Width Range: 37" to 42" (94cm to 107cm)
- No Cutting Required: 42" door
- Door Types: Wood or metal
- Minimum Stile Width: 1-3/4" (44mm)
- Grade: ANSI/BHMA Grade 1
