Description
The Sargent 5556-AD8613F ETA RHR exit device is a Grade 1 rim-mounted panic bar designed for metal doors 1 3/4" to 2 1/4" thick. Built for facilities requiring durable, maintenance-free egress hardware, it features modular construction and exceeds ANSI/BHMA Grade 1 cycle and strength requirements. The 32D satin stainless steel finish resists corrosion and blends with modern architectural styles.
This device suits E, F, J, or G rail configurations depending on door width (24" to 48"), with factory cutting available. Pair it with 650 top and 606 bottom strikes rated for panic and fire-rated doors. Optional electric features including delayed egress, alarms, and latch retraction are available. Contact our authorized dealer specialists at sales@edlocks.com or 1-877-207-6067 for configuration guidance and fast shipping.
Specifications
- Brand: Sargent
- Model: 5556-AD8613F ETA RHR
- Finish: 32D Satin Stainless Steel
- Door Thickness: 1 3/4" to 2 1/4" minimum
- Door Width Range: 24" to 48" (E, F, J, G rails)
- Minimum Stile Width: 4 1/2"
- Device Centerline: 41" standard, 38" for accessible applications
- Maximum Door Height: 96"
- Center Case: 8 3/8" x 2 5/8"
- Pushbar Projection: 3" neutral, 2 1/8" depressed
- Strike Configuration: 650 top, 606 bottom (panic and fire-rated)
- Dogging: Hex key standard
- Grade: ANSI/BHMA Grade 1
