Description
The Sargent 80 Series exit device is a Grade 1 rated panic bar solution for metal doors requiring durable, long-lasting security. Ideal for commercial facilities, schools, and high-traffic environments, this rim-mounted device combines modular construction with minimal moving parts for maintenance-free operation and reliable emergency egress control.
This left-hand reverse (LHR) model fits metal doors 1.75 inches minimum thickness and 4.5 inches minimum stile width. Rails are factory-cut to your door width (24-48 inches). Optional features include alarm, photoluminescent coating, touchpad illumination, and electric latch retraction. Contact our security experts at sales@edlocks.com or 1-877-207-6067 for installation guidance and to verify compatibility with your specific door and application requirements.
Specifications
- Brand: Sargent
- Series: 80 Series
- Model: 5556-MD8606F LHR 20D
- Configuration: Rim-mounted
- Rating: ANSI/BHMA Grade 1
- Door Types: Metal doors, minimum 1.75 inches (44mm) thick
- Minimum Stile Width: 4.5 inches (114mm)
- Device Centerline Height: 41 inches (1041mm) standard; 38 inches (965mm) for elementary schools
- Center Case Dimensions: 8.375 inches (213mm) x 2.625 inches (67mm)
- Pushbar Projection: 3 inches (76mm) neutral, 2.125 inches (54mm) depressed
- Top Bolt: Stainless steel
- Maximum Door Height: 96 inches
- Maximum Door Opening: 120 inches (3048mm)
- Dogging: Hex key standard (non-fire rated); cylinder option available
- Strike: 650 Top Strike and 606 Bottom Strike (panic and fire rated)
- Mounting Fasteners: Machine screws supplied
- Optional Features: Alarm, Beacon, photoluminescent coating, illuminated touchpad, latchbolt monitor, outside lever monitoring, request-to-exit signal, remote latch retraction, delayed egress with electromagnets, electric dogging
