Description
The Sargent 80 Series rim exit device is engineered for commercial facilities demanding durable, maintenance-free egress hardware. Built with modular construction and minimal moving parts, this Grade 1 certified device provides reliable security and smooth operation across wood or metal doors 1 3/4 inches thick, with rail options accommodating door widths from 24 to 48 inches.
Installation is straightforward on standard door thicknesses; thicker doors require a 31-prefix order. Choose from E, F, J, or G rails based on your door width for a no-cut fit. As an authorized Sargent dealer, E.D. Locks offers expert guidance on configuration, delayed egress, alarmed exit, and electric latch retraction options. Contact our specialists at sales@edlocks.com or 1-877-207-6067 for technical support.
Specifications
- Model: 56-8540G ETB LHR 32D
- Configuration: Rim exit device, left-hand reverse
- Door Types: Wood or metal
- Door Thickness: 1 3/4 inch (44mm) standard; specify thickness over 1 3/4 inch
- Minimum Stile Width: 1 3/4 inch (44mm)
- E Rail: 24 to 32 inches (no cut at 32 inch)
- F Rail: 33 to 36 inches (no cut at 36 inch)
- J Rail: 37 to 42 inches (no cut at 42 inch)
- G Rail: 43 to 48 inches (no cut at 48 inch)
- Grade: ANSI/BHMA Grade 1
