Description
The Sargent 80 Series exit device is a heavy-duty push bar designed for wood and metal doors in commercial facilities requiring ANSI/BHMA Grade 1 certified security. This rim-mounted, right-hand reverse model solves the need for durable, maintenance-free egress hardware that exceeds industry standards and supports life-cycle building security with minimal moving parts.
The 56-NB8713E fits 1-3/4 inch thick doors with E-rail configurations (24-32 inches wide) and requires no cutting for 32 inch doors. It accommodates thicker doors when ordered with a 31-prefix. Options include delayed egress, alarmed exit, and electric latch retraction. Contact our authorized dealer specialists at sales@edlocks.com or 1-877-207-6067 for expert installation guidance and configuration support.
Specifications
- Brand: Sargent
- Model: 56-NB8713E ETF RHR 32D
- Configuration: Rim-mounted, right-hand reverse
- Door Types: Wood or metal
- Door Thickness: 1-3/4 inch (44mm)
- Door Width (E-Rail): 24-32 inches (61-81cm); no cutting required at 32 inches
- Minimum Stile: 4-1/2 inch with trim, 3-1/2 inch without trim
- Certification: ANSI/BHMA Grade 1
- Features: Modular construction, maintenance-free, options for delayed egress, alarmed exit, electric latch retraction
