Description
The LCN 6032-BUMPER AL is a concealed-in-door closer engineered for narrow headers requiring minimal 1-3/4" clearance. This heavy-duty, double-acting unit delivers smooth, quiet door control via a single lever arm and roller assembly, ideal for interior doors up to 4'6" and exterior doors to 3'6".
The 6032-BUMPER ships complete with standard arm, track with bumper, mounting plate, and fastener packs. Spring power and latch speed adjust independently per swing, while backcheck and general speed are common. ADA compliant. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for finish options, corrosive-environment primers, and expert installation guidance.
Specifications
- Series: 6030 Pacer
- Type: Concealed-in-door, double-acting
- Minimum header clearance: 1 3/4" (44 mm) x 4" (102 mm)
- Interior door capacity: Up to 4'6"
- Exterior door capacity: Up to 3'6"
- Arm: Single lever with roller assembly
- Included: Standard arm, track with bumper, mounting/finish plate, wood and machine screw pack
- Finish options: Standard powder coat, optional plated finish, optional SRI primer for corrosive environments
- ADA compliant
- Adjustments: Independent spring power and latch speed per swing; common backcheck and general speed
