Description
The Sargent 8272-24V is a field-changeable electromechanical mortise lock designed for single-opening and access control applications. With 12V-24V operation, fail safe/fail secure switching, and ANSI/BHMA Grade 1 certification, it solves security needs for commercial doors requiring both electronic control and traditional keying.
Compatible with standard 1 3/4" (44mm) doors and ANSI A115.1 strike plates, this lock features stainless steel construction, reversible latchbolt, and available masterkeying. An authorized E.D. Locks dealer can help with hand specification, finish selection, and integration into your access system. Contact us at sales@edlocks.com or 1-877-207-6067 for expert guidance.
Specifications
- Voltage: 12V-24V DC
- Backset: 2 3/4" (70mm)
- Case: 12 gauge wrought steel, zinc dichromate plated, 7/64" (3mm) thick
- Front Plate: 8" x 1 1/4" (203mm x 31mm), ANSI Standard A115.1, adjustable flat to beveled 1/8" (3mm)
- Latchbolt: Stainless steel, 3/4" (19mm) projection, reversible
- Deadbolt: Hardened stainless steel, 1" (25mm) projection
- Cylinder: Brass, size #41 (1 1/8") standard
- Keys: Two nickel silver
- Finishes: 3, 4, 9, 10, 10B, 10BL, 15, 20D, 26, 26D, 32, 32D
- Classroom Security: 38, 39, 40, 41
- Minimum Stile: 4 1/2" (114mm)
- UL Listed for fire doors
- Warranty: 2 year limited warranty on electrified locks
