Description
The Adams Rite 8500LR-30-US32D is a heavy-duty exit device designed for hollow metal doors in commercial buildings. This electric latch retraction model with satin stainless steel finish solves code compliance and emergency egress requirements for facilities managers and building owners who need reliable panic hardware on standard interior or exterior doorways.
Compatible with 1-3/4" to 2-1/4" thick doors up to 8 feet tall, the device features a non-handed extruded aluminum pushbar that can be field cut and adjusted from 30" to 44" in height. Installation uses standard self-tapping screws or optional sex bolt kits. As an authorized Adams Rite dealer, E.D. Locks provides expert sizing, keying, and compliance guidance; contact sales@edlocks.com or call 1-877-207-6067 for assistance selecting cylinders and trim options.
Specifications
- Brand: Adams Rite
- Model: 8500LR-30-US32D
- Function: CVR Exit Device, Electric Latch Retraction
- Pushbar Length: 30" (standard, field cuttable)
- Pushbar Height Range: 30" to 44" adjustable
- Finish: Satin Stainless Steel
- Material: Extruded aluminum, anodized
- Door Thickness: 1-3/4" to 2-1/4"
- Maximum Door Height: 8 feet (40-44" bar height); 10 feet with optional Tall Door Kit
- Minimum Stile Width: 3-3/4"
- Projection: 2-15/16" fully projected, 1-15/16" dogged
- Handing: Non-handed, field reversible entry trim
- Dogging: Standard hex key (cylinder dogging optional)
- Warranty: Five year limited
- Door Type: Hollow metal
