Description
The Sargent 8504E ETW RHR 10B is a heavy-duty rim exit device built for facilities demanding maximum security and durability. Engineered to exceed ANSI/BHMA Grade 1 standards, this right-hand reverse model features modular construction with minimal moving parts, delivering maintenance-free operation and reliable egress control for wood or metal doors up to 48 inches wide.
Designed for 1 3/4 inch doors (thicker doors available with 31-prefix ordering), the 8504E installs on E, F, J, or G rails depending on your door width. Choose from options including delayed egress, alarmed exit, and electric latch retraction for specialized applications. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for expert help selecting the right configuration and ensuring proper installation.
Specifications
- Brand: Sargent
- Model: 8504E ETW RHR 10B
- Configuration: Rim Exit Device, Right-Hand Reverse
- Door Types: Wood or Metal
- Door Thickness: 1 3/4 inch (44mm) standard; thicker doors available with 31-prefix
- Minimum Stile Width: 1 3/4 inch (44mm)
- E Rail: 24 inch to 32 inch doors (61cm to 81cm)
- F Rail: 33 inch to 36 inch doors (84cm to 91cm)
- J Rail: 37 inch to 42 inch doors (94cm to 107cm)
- G Rail: 43 inch to 48 inch doors (110cm to 122cm)
- Standard: Exceeds ANSI/BHMA Grade 1
- Options: Delayed egress, alarmed exit, electric latch retraction
