Description
The Sargent 8504F ETP RHR 10B is a heavy-duty rim exit device built for commercial facilities demanding maximum durability and security. Ideal for wood or metal doors, this Grade 1 rated device features modular construction with minimal moving parts, ensuring maintenance-free operation throughout the building's life while providing reliable emergency egress control.
Compatible with 1-3/4" thick doors (44mm minimum stile) and available in multiple rail sizes to fit 24" to 48" door widths without cutting for standard sizes. This device supports optional configurations including delayed egress, alarm, and electric latch retraction for specialized applications. Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for expert guidance on rail selection and installation to ensure proper fit and function.
Specifications
- Series: Sargent 80
- Configuration: Rim, right-hand reverse (RHR)
- Door Thickness: 1-3/4" (44mm) standard; over 1-3/4" order with 31- prefix
- Door Width - E Rail: 24" to 32" (61cm to 81cm); no cutting at 32"
- Door Width - F Rail: 33" to 36" (84cm to 91cm); no cutting at 36"
- Door Width - J Rail: 37" to 42" (94cm to 107cm); no cutting at 42"
- Door Width - G Rail: 43" to 48" (110cm to 122cm); no cutting at 48"
- Grade: ANSI/BHMA Grade 1
- Door Types: Wood or metal
- Options: Delayed egress, alarmed exit, electric latch retraction
