Description
The Sargent 8706F is a rim-mounted exit device built for high-traffic commercial doors. Designed for wood or metal doors 1 3/4" thick, it combines ANSI/BHMA Grade 1 strength with modular construction that requires minimal maintenance. Ideal for facilities prioritizing durable, long-lasting security and reliable emergency egress.
This right-hand reverse (RHR) model fits doors 24" to 32" wide without cutting. The 80 Series exceeds industry cycle and strength standards while supporting optional features like delayed egress, alarmed exit, and electric latch retraction. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for compatibility verification and expert installation guidance.
Specifications
- Brand: Sargent
- Model: 8706F ETJ RHR 32D
- Configuration: Rim-mounted exit device
- Door Thickness: 1 3/4" (44mm)
- Door Width Range: 24" to 32" (61cm to 81cm)
- Minimum Stile: 4 1/2" with trim; 3 1/2" without trim
- Handedness: Right-hand reverse (RHR)
- Grade: ANSI/BHMA Grade 1
- Rail Type: E Rail
- Compatible Door Types: Wood or metal
- Features: Modular construction, maintenance-free, optional delayed egress, alarmed exit, electric latch retraction
