Description
The Sargent 8706F is a heavy-duty rim exit device built for commercial and institutional facilities requiring Grade 1 security and reliability. Engineered to exceed ANSI/BHMA standards, it delivers superior cycle performance and strength with minimal maintenance. Its modular design makes it ideal for wood or metal doors needing dependable panic hardware that lasts the building's lifetime.
This left-hand reverse (LHR) model fits 1-3/4 inch doors with 24 to 32 inch widths; thicker doors and wider openings require different specifications. The Sargent 80 Series supports delayed egress, alarmed, and electric latch retraction options for specialized applications. Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for expert configuration advice and authorized dealer support.
Specifications
- Brand: Sargent
- Model: 8706F LHR 32D
- Type: Rim exit device
- Door thickness: 1-3/4 inch (44mm)
- Door width range: 24 to 32 inches (61-81cm)
- No cutting required for 32 inch doors
- Minimum stile: 4-1/2 inch with trim, 3-1/2 inch without trim
- Standard: ANSI/BHMA Grade 1
