Description
The Sargent 8706G ETF exit device is a heavy-duty rim-mounted panic bar designed for wood and metal doors in high-traffic commercial facilities. Built to exceed ANSI/BHMA Grade 1 requirements, this left-hand reverse exit device provides reliable emergency egress and superior security with modular construction and minimal maintenance needs.
Compatible with 1-3/4" to 2-1/4" thick doors and available in E, F, J, and G rail configurations for door widths from 24" to 48". Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for help selecting the correct rail size, installation guidance, and options like delayed egress or electric latch retraction.
Specifications
- Model: 8706G ETF LHR 32D
- Configuration: Rim, left-hand reverse
- Compatible door thickness: 1-3/4" to 2-1/4" (44mm to 57mm)
- E Rail door width: 24" to 32" (61cm to 81cm), no cutting required for 32" doors
- F Rail door width: 33" to 36" (84cm to 91cm), no cutting required for 36" doors
- J Rail door width: 37" to 42" (94cm to 107cm), no cutting required for 42" doors
- G Rail door width: 43" to 48" (110cm to 122cm), no cutting required for 48" doors
- Minimum stile width: 4-1/2" (114mm) with trim, 3-1/2" (44mm) without trim
- Grade: ANSI/BHMA Grade 1
- Door types: Wood or metal
