Description
The Adams Rite 8802A-48B is a rim exit device designed for narrow stile aluminum doors up to 48 inches wide. This battery-operated alarm model suits standard 1-3/4" to 2-1/4" door thickness and adjusts from 30" to 44" bar height, fitting doors up to 8 feet tall. It solves the need for reliable emergency egress on commercial aluminum storefronts and narrow frame applications.
The device is non-handed with field-reversible lever entry trim and accepts standard rim cylinders. The extruded aluminum pushbar is available in multiple finishes. For expert sizing, finish selection, or to discuss keying options, contact E.D. Locks, an authorized Adams Rite dealer, at sales@edlocks.com or 1-877-207-6067. We offer free shipping on orders over $450.
Specifications
- Brand: Adams Rite
- Model: 8802A-48B
- Pushbar Length: 48 inches
- Bar Height Adjustment: 30" to 44"
- Door Thickness: 1-3/4" to 2-1/4"
- Maximum Door Height: 8 feet (standard)
- Minimum Stile Width: 3-3/4"
- Projection: 2-15/16" extended, 1-15/16" dogged
- Handing: Non-handed
- Operation: Battery operated alarm
- Material: Extruded aluminum pushbar
- Dogging: Standard hex key or optional cylinder dogging
- Cylinder Compatibility: Standard rim cylinder
- Warranty: Five year limited
