Description
The Adams Rite 8803C-36 is a rim exit device designed for narrow stile aluminum doors up to 36 inches wide. Built with an extruded aluminum pushbar in black finish, it features cylinder dogging for secure, controlled egress. Perfect for commercial buildings, storefronts, and facilities requiring ADA-compliant emergency exits with keyed control.
This non-handed device fits standard 1-3/4" to 2-1/4" door thickness and adjusts from 30" to 44" bar height, accommodating doors up to 8 feet tall. It accepts standard rim cylinders (sold separately) for flexible keying options. As an authorized Adams Rite dealer, E.D. Locks provides expert sizing guidance and installation support. Contact sales@edlocks.com or call 1-877-207-6067 for assistance selecting the right cylinder and trim configuration for your application.
Specifications
- Brand: Adams Rite
- Model: 8803C-36
- Pushbar Length: 36 inch
- Pushbar Material: Extruded aluminum, anodized black
- Handing: Non-handed, field reversible
- Bar Height Range: 30 inch to 44 inch
- Door Thickness: 1-3/4 inch to 2-1/4 inch
- Maximum Door Height: 8 feet (at 40-44 inch bar height)
- Minimum Stile Width: 3-3/4 inch
- Projection: 2-15/16 inch extended, 1-15/16 inch dogged
- Dogging: Cylinder dogging
- Cylinder Type: Standard rim cylinder (sold separately)
- Warranty: Five year limited
