Description
The LCN 9550 Series is a power-operated door system designed for ADA-compliant automatic or manual egress in commercial buildings. This simultaneous pair operator ships complete with motor gearboxes, control box, arms, header, and mounting hardware, solving accessibility and traffic flow challenges in high-traffic facilities. Pull, push, or double egress configurations are available.
The 9550-334-1 628 mounts surface-style with a standard 72-inch header; custom lengths from 60 to 98 inches are available by consulting the factory. Hold-open time adjusts from 1 to 32 seconds in automatic or manual mode. As an authorized LCN dealer, E.D. Locks offers expert configuration guidance and support. Contact sales@edlocks.com or call 1-877-207-6067 to specify the right setup for your application.
Specifications
- Series: 9550
- Model: 9550-334-1 628
- Mounting: Surface mounted
- Standard header length: 72 inches
- Custom header length range: 60 to 98 inches
- Hold-open adjustment: 1 to 32 seconds
- Modes: Automatic or manual
- ADA compliant: Power mode only
- Configurations: Pull, push, or double egress
- Components included: Motor gearboxes, control box, arms, header, mounting hardware
- Actuators: Available separately
