Description
The HES 9600 Series is a surface-mounted electric strike engineered for rim exit devices with 3/4" throw latches. Windstorm-rated and built into a 3/4" thick stainless steel housing, it requires no frame cutting and installs directly onto metal or wood frames. Ideal for facilities needing flexible fail-safe or fail-secure operation with field-selectable 12 or 24VDC power.
This non-handed strike features latchbolt monitoring (LBM) for enhanced security feedback and delivers exceptional durability with 2,000 lbs static strength and 1,000,000-cycle endurance. As an authorized HES dealer, E.D. Locks provides expert installation guidance and ongoing support at sales@edlocks.com or 1-877-207-6067 to ensure your strike performs reliably for years to come.
Specifications
- Model: 9600-612-LBM
- Finish: Satin Bronze (612)
- Latchbolt Monitor: Yes (LBM)
- Voltage: Field Selectable 12 or 24VDC
- Current Draw: 0.45A at 12VDC, 0.25A at 24VDC (Continuous Duty)
- Static Strength: 2,000 lbs
- Dynamic Strength: 120 ft-lbs
- Endurance: 1,000,000 Cycles
- Housing Thickness: 3/4"
- Latch Accommodation: Up to 3/4" Pullman Latch
- Operation: Field Selectable Fail Safe / Fail Secure
- Mounting: Surface Mount, Non-Handed
- Frame Compatibility: Metal or Wood
- Installation: No Frame Cutting Required
- Warranty: Five-Year Limited
