Description
The Sargent 80 Series AD8610E is a rim exit device engineered for metal doors requiring durable, long-lasting security. Ideal for commercial facilities, schools, and institutional buildings, this Grade 1 device combines robust construction with modular design to eliminate maintenance while exceeding ANSI/BHMA cycle and strength standards.
Installation fits metal doors 1-3/4" minimum thickness with 4-1/2" minimum stile width. Rail size E (24-32" door widths) is included; rails are factory-cut to specification. Configure with optional delayed egress, alarms, or electric latch retraction for your specific application. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for expert guidance on keying and compatibility with your door assembly.
Specifications
- Brand: Sargent
- Series: 80 Series
- Model: AD8610E ETF RHR 32D
- Door Type: Metal, 1-3/4" (44mm) minimum thickness
- Minimum Stile Width: 4-1/2" (114mm)
- Rail Configuration: E Rail included (24-32" door widths, no cutting required for 32" doors)
- Strike: 650 Top Strike & 606 Bottom Strike (Panic and Fire Rated)
- Device Centerline: 41" (1041mm) from finished floor (standard); 38" (965mm) for elementary schools
- Center Case Dimensions: 8-3/8" (213mm) x 2-5/8" (67mm)
- Pushbar Projection (Neutral): 3" (76mm)
- Pushbar Projection (Depressed): 2-1/8" (54mm)
- Top Bolt: Stainless steel
- Dogging: Hex key dogging standard (non fire-rated); cylinder dogging available (#41 cylinder supplied)
- Maximum Door Height: 96" (HC and WS options)
- Maximum Door Opening Height: 120" (3048mm)
- Fasteners: Machine screws supplied standard
