Description
The Sargent 80 Series exit device (model AD8615F RHR 10BE) provides Grade 1 security for metal doors in commercial and institutional buildings. Designed for environments demanding durability and reliability, this rim-mounted device exceeds ANSI/BHMA standards with modular construction, minimal maintenance requirements, and unsurpassed security for any facility type.
This right-hand reverse (RHR) configuration suits door widths from 24 to 48 inches with four factory-cut rail options. Compatible with standard machine screw fasteners and available strike plates (650 top, 606 bottom), the device supports optional delayed egress, alarmed exit, and electric latch retraction features. Contact E.D. Locks' expert team at sales@edlocks.com or 1-877-207-6067 for application guidance and authorized dealer support.
Specifications
- Brand: Sargent
- Model: AD8615F RHR 10BE
- Configuration: Rim-mounted, right-hand reverse
- Door Thickness: 1-3/4 inch minimum (44mm)
- Minimum Stile Width: 4-1/2 inches (114mm)
- Compatible Door Widths: 24 to 48 inches (E, F, J, G rail options)
- Device Centerline from Floor: 41 inches (1041mm) standard; 38 inches (965mm) for accessibility
- Maximum Door Height: 96 inches
- Center Case Dimensions: 8-3/8 inch x 2-5/8 inch (213mm x 67mm)
- Pushbar Projection (Neutral): 3 inches (76mm)
- Pushbar Projection (Depressed): 2-1/8 inches (54mm)
- Top Bolt: Stainless steel
- Strike Plates: 650 top, 606 bottom (panic and fire-rated)
- Dogging: Hex key standard; cylinder dogging available
- Fasteners: Machine screws supplied standard
- Grade: ANSI/BHMA Grade 1
