Description
The Schlage AL170 is a Grade 2 commercial lever lock engineered for high-traffic environments like offices, banks, retail spaces, and hotel guest rooms. ADA compliant and non-handed, it delivers dependable security and constant performance in buildings with medium to high foot traffic, solving the need for durable, accessible door hardware.
This lock accommodates door thicknesses from 1 3/8" to 1 7/8" standard, with optional 2" thickness. It features a deadlocking latch, steel construction with zinc dichromated corrosion resistance, and a 6-pin Everest 29 S123 keyway. As an authorized Schlage dealer, E.D. Locks offers expert guidance on backset options, keying configurations, and master keying. Contact sales@edlocks.com or 1-877-207-6067 for technical support and a three-year limited warranty.
Specifications
- Brand: Schlage
- Model: AL170 OME 613 (ALX Series)
- Grade: 2
- Handing: Non-handed
- Door Thickness: 1 3/8" to 1 7/8" (35-48 mm) standard; 2" (51 mm) optional
- Backset: 2 3/4" (70 mm) standard; 2 3/8" (60 mm), 3 3/4" (95 mm), 5" (127 mm) optional
- Front: Steel, 2 1/4" x 1 1/8" square corner beveled standard
- Lock Chassis: Steel, zinc dichromated
- Latch Bolt: Brass, chrome plated, 1/2" throw, deadlocking
- Exposed Trim: Wrought brass and bronze; levers pressure cast zinc
- Strike: ANSI curved lip strike 4 7/8" x 1 1/4" x 1 1/4" standard
- Cylinder: 6-pin Everest 29 S123 keyway
- Keys: Two nickel silver keys per lock
- Keying Options: Interchangeable core, Primus high security, master keying, grand master keying, construction keying
- Warranty: Three-year limited
