Description
The Arrow GL87-SR-26D is a Grade 1 cylindrical lever lock engineered for classroom security and ADA-compliant access. This satin chrome finish lock solves the need for economical, durable hardware that meets institutional standards while minimizing installation complexity through fewer subcomponents and streamlined design.
Compatible with standard 2-1/8 inch bore doors from 1-3/8 to 2 inches thick, the GL87 features removable thru-bolts, stainless steel latch with 1/2 inch throw, and non-handed operation for flexible installation. Our authorized dealer status means you get expert configuration guidance via sales@edlocks.com or 1-877-207-6067, plus a five-year limited warranty.
Specifications
- Brand: Arrow
- Model: GL87-SR-26D
- Grade: 1
- Function: Classroom (latchbolt operated by lever either side; key outside locks/unlocks outside lever only)
- Finish: Satin Chrome (US26D)
- Door Bore: 2-1/8 inch standard
- Edge Bore: 1 inch
- Backset: 2-3/4 inch standard
- Latch Throw: 1/2 inch stainless steel
- Latch Front: 2-1/4 inch x 1-1/8 inch
- Strike: ANSI A115.2 curved lip, 4-7/8 inch x 1-1/4 inch
- Door Thickness: 1-3/8 to 2 inches
- Handing: Non-handed, bi-directional levers
- Housing: Dichromate plated steel with rose insert
- Trim: Pressure cast zinc levers
- Feature: OverDrive freewheeling lever action
- Warranty: Limited five years
- Available Finishes: US3, US10B, US26D
