Description
The Yale 8800 Series mortise lock trim pack is engineered for commercial doors demanding uncompromising strength and durability. This ANSI/BHMA Grade 1 certified lock features a reinforced stainless steel deadbolt, heavy-duty vandal-resistant trim, and UL/cUL fire rating up to 3 hours, making it ideal for high-traffic institutional and commercial applications.
The AUCN8809FL includes field-reversible handing, quick lever installation, and a standard nonhanded strike for fast setup. Fits 1-3/4" standard doors and comes with a 6-pin keyed-random cylinder and two keys. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for finish selection, keying options, and expert installation guidance.
Specifications
- Certification: ANSI/BHMA A156.13, Series 1000, Grade 1
- Fire Rating: UL/cUL up to 3 hours
- Mechanism: Stainless steel
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard (up to 3-1/4" available)
- Cylinder: Brass, 6-pin keyed-random with two keys (7-pin available)
- Strike: 1-1/4" curved lip for 1-3/4" door (other lengths to order)
- Reversibility: Field reversible handing
- Finishes: 17 available
- Warranty: 10 years mechanical
