Description
The Yale 8800 Series mortise lock trim pack is a Grade 1 commercial-grade security solution for standard interior and exterior doors. Designed for uncompromising strength and durability, it features a reinforced stainless steel deadbolt, heavy-duty vandal-resistant trim, and field-reversible handing to solve installation challenges across diverse commercial applications.
This trim pack fits 1-3/4" standard door thickness and installs with quick lever handing and a standard nonhanded strike for flexibility. Compatible with 6-pin keyed-random cylinders (two keys included). As an authorized Yale dealer, E.D. Locks provides expert support and guidance at sales@edlocks.com or 1-877-207-6067 to ensure proper specification and installation for your security needs.
Specifications
- ANSI/BHMA Certified A156.13, Series 1000, Operational Grade 1
- UL/cUL fire rated up to 3 hours
- Windstorm certified
- Mechanism: Stainless steel
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door thickness: 1-3/4" standard (to 3-1/4" available to order)
- Front: Bevel front, free-floating 1/8" in 2" adjustment
- Cylinders: Brass, 6-pin keyed-random with two keys (7-pin available)
- Field reversible handing
- Strike: 1-1/4" curved lip for 1-3/4" door (other lengths available)
- Available in 17 finishes
- 10-year mechanical warranty
