Description
The Yale 8800 Series mortise lock trim pack is a Grade 1 commercial-duty lock designed for high-security applications in offices, hospitals, and institutional buildings. It features a reinforced stainless steel deadbolt, vandal-resistant trim, and field-reversible handing to simplify installation and reduce costs on multi-door projects.
This trim pack is compatible with standard 1-3/4" doors and includes a 6-pin keyed-random cylinder with two keys. Installation is straightforward thanks to quick lever handing and a standard nonhanded strike. As an authorized Yale dealer, E.D. Locks offers expert guidance on finish selection, keying options, and compatibility. Contact our team at sales@edlocks.com or 1-877-207-6067 for personalized support.
Specifications
- ANSI/BHMA Certification: A156.13, Series 1000, Grade 1
- UL/cUL Fire Rating: Up to 3 hours
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard (up to 3-1/4" available)
- Front: Bevel front, free-floating (flat to 1/8" bevel in 2")
- Cylinder: Brass, 6-pin, keyed-random with 2 keys (7-pin available)
- Strike: 1-1/4" curved lip for 1-3/4" door (reversible)
- Field Reversible: Yes
- Available Finishes: 17 options
- Warranty: 10 years mechanical
