Description
The Schlage B560P deadbolt is a heavy-duty mortise lock designed for commercial and residential doors requiring maximum security and durability. It solves the problem of weak jamb-side anchoring with an integrated anti-pry shield, thicker metal strike backup, and a third screw for deeper fastening. This lock suits locksmiths and property managers who need universal cylinder compatibility and reliable performance across diverse door types.
The B560P accepts any Schlage cylinder and fits virtually every door with its adjustable backset. Installation requires standard mortise preparation. As an authorized dealer, E.D. Locks offers expert guidance on keying, finish selection, and compatibility. Contact our team at sales@edlocks.com or 1-877-207-6067 for technical support and volume pricing on Schlage products.
Specifications
- Series: B500
- Model: B560P 643E KA4
- Bolt Construction: Seamless steel latch, 10% larger diameter deadbolt
- Bolt Material: Zinc with spinning hardened steel pin
- Anti-Pry Shield: Integrated
- Strike: Thicker metal security strike with third screw anchoring
- Backset: Adjustable with lock-in-place helix design
- Front Housing: Tapered, non-unscrewable design
- Thumbturn: Large, ADA compliant
- Latch Box: Expanded space for true deadlatch
- UL Ratings: UL 10B, UL 10C
- Cylinder Compatibility: All Schlage cylinders
