Camden CM-400 Series Mushroom Push Switch

Camden CM-400 Series Mushroom Push Switch

Camden CM-400 Series Mushroom Push Switch
$60.48


Camden Door Controls CM-400 Series mushroom push switches are medium duty push-button controls. Buttons are available in red, with a 1 5/8” (40 mm) diameter. The buttons are free-spinning, for protection against vandalism. They are supplied with an industrial grade stainless steel faceplate, in one gang widths. The switches are UL /CSA approved, rated 10 AMPS @ 30V DC.

Application

Camden push switches are designed to control overhead doors, electric locks, electromagnetic locks, electric strikes, automatic doors, and handicap operators. They may also be used for shunting, bypassing alarms, request to exit, timed functions, and many other applications. The switches are made for high frequency usage, in an indoor or outdoor environment. Easily visible, they are available with one gang or two gang stainless steel mounting plates. Camden push switches are versatile, and are supplied in numerous configurations to suit varied commercial and industrial applications.

Features

  • LARGE, EASY TO OPERATE RED BUTTON
  • 1 5/8” (40 MM) DIAMETER
  • FREE-SPINNING, HEAVY-DUTY BUTTON CANNOT BE UNSCREWED
  • STAINLESS STEEL, SINGLE GANG FACEPLATE
  • UL294 MODELS
  • UL /CSA APPROVED SWITCH, RATED 10 AMPS @ 30V DC
  • FAST AND EASY TO INSTALL
  • FINISH: BRUSHED ALUMINUM

Specifications

The push switches to be used throughout the site/complex shall be Camden Door Controls CM-400 series push switches. The button shall be easy to activate, 1 5/8” (40 mm) in diameter. The faceplate shall be constructed of industrial grade stainless steel, and shall be supplied with stainless steel security screws. The push button shall be free-spinning for additional protection against vandalism. Rating for all electrical contacts, shall be a minimum of 10 amps @ 30 VDC. The switch used shall be a UL/CSA approved type, supplied with color coded spade leads. The switch assembly shall be modular, allowing for up to six distinct functions upon activation of the push-button. The mounting shall employ a bayonet assembly, so that no set screws are required to secure the free spinning button.

Model Available: CM-400/1 SPRING RETURN PLAIN FACEPLATE, SPST, N/O
