Description
The Von Duprin CD3327AEO 4 315 is a UL-listed panic exit device designed for single and double doors in commercial buildings. Built to ANSI A156.3 Grade 1 standards, it features a grooved mechanism case, deadlocking anti-friction bolts, and a 3 13/16 inch pushbar projection. This exit-only device is ideal for life safety compliance in high-traffic applications.
Compatible with doors 3'0 to 4'0 wide and up to 7'0 tall, with extension rods available for taller openings. Installation requires proper alignment at 39 13/16 inches from finished floor. As an authorized Von Duprin dealer, E.D. Locks provides expert guidance on sizing, keying options, and compliance. Contact sales@edlocks.com or call 1-877-207-6067 for personalized support.
Specifications
- Model: CD3327AEO 4 315
- Grade: ANSI A156.3 2008 Grade 1
- Device Type: Surface vertical rod, exit only
- Case Style: Grooved mechanism case
- Door Width Range: 3'0 to 4'0
- Standard Door Height: Up to 7'0
- Centerline Height: 39 13/16 inches from finished floor
- Center Case Dimensions: 8 13/16 x 2 13/32 x 1 9/16 inches
- Mechanism Case: 2 1/4 x 2 1/4 inches
- Pushbar Projection (Neutral): 3 13/16 inches
- Pushbar Projection (Depressed): 3 1/16 inches
- Latch Bolt: Deadlocking anti-friction, 5/8 inch throw
- Vertical Rods: 1/2 inch square tubing
- Rod Lengths: Top 34 15/16 inches, Bottom 31 1/4 inches
- Extension Rods: Available in 1 foot or 3 foot lengths
- Door Undercut: 1/4 inch maximum
- Fasteners: #325 SNB furnished standard for EO device
- Compatible Door Types: Wood and metal doors 1 3/4 to 2 1/4 inches thick
- UL Listed: Yes
