Description
The Von Duprin CD35ANL-OP 4 313 is a UL-listed rim exit device designed for single and double doors with mullions. Built to ANSI A156.3-2014 Grade 1 standards, this panic hardware provides reliable emergency egress for commercial facilities, schools, hospitals, and other high-traffic environments where code-compliant exits are mandatory.
Compatible with door sizes 4' 2" to 4' in width and installation heights of 39 11/16" to 39 13/16" from finished floor, this device is non-handed (except with signal switch options). For proper selection of outside trim, functions, and installation on your specific door type, contact our security experts at sales@edlocks.com or 1-877-207-6067 for personalized guidance and faster service.
Specifications
- Brand: Von Duprin
- Model: CD35ANL-OP 4 313
- UL Listed Panic Exit Hardware
- Grade: ANSI A156.3-2014 Grade 1
- Compatible Door Widths: 4' 2" to 4'
- Device Centerline Height: 39 11/16" to 39 13/16" from finished floor
- Center Case Dimensions: 8 3/16" x 1 9/16" x 2 13/32"
- Mechanism Case Dimensions: 2 1/4" x 2 1/4"
- Pushbar Projection (Neutral): 3 13/16"
- Pushbar Projection (Depressed): 3 1/16"
- Latch Bolt: Deadlocking, 3/4" throw
- Device Lengths: 2' 4" to 3'
- Non-Handed (except with SS signal switch option)
- Compatible with single and double doors with mullion
