CDC-84-S-626 TownSteel Cylindrical Lock

The CDC/CD Series Cylindrical Lockset is ANSI/BHMA A156.2-2011 Grade 1 certified and UL 10C 3-Hour rated. Both clutched and rigid trims are available. Independent torsion spring design provides effective lever support. It offers three types of lever available in US26D and US10B finishes. Most BHMA functions are available. Easy installation.

CE Series

• Door Thickness: 1-3/4" - 2"
• Backset: 2-3/4" Standard, 5" Optional
• Latch Bolt: Stainless Steel, 1/2" throw
• Faceplate: Self-adjustable, 1-1/8" x 2-1/4" Stainless Steel

CDC Series

• Door Thickness: 1-3/8" - 2"
• Backset: 2-3/4" Standard, 2-3/8", 3-3/4", 5" Optional
• Latch Bolt: Stainless Steel, 1/2" (12.7mm) throw, deadlocking on keyed functions. Anti-friction fire door latch with 3/4" (19mm) throw available upon request
• Faceplate: Forged brass or Stainless Steel, 1-1/8" X 2-1/4" (29mm X 57mm) square corner, beveled.
